UPEL-P

Chemical hose

Application: UPEL-P, the chemical protection hose with a black, conductive UPE liner. Suitable for the transport of acids, alkalis, salts, organic compounds (alcohols, esters, ketones, etc.) incl. aromatic substances, chlorinated hydrocarbons and oxidising acids according to our chemical resistance list.

Feature: The Resist U tube has an extremely low friction coefficient and good abrasion resistance.

Standard / approval: EN 12115:2011, TRbF 131/2:1992.
Notice:
ATTENTION: The temperature of the medium must be lower than its boiling point.
ATTENTION: Please refer to the Ramer Group resistance list or, in case of doubt, contact Ramer Group.

ATTENTION: Continuous use at the peak values reduces the service life.
ATTENTION: To ensure the assembly is leakproof, it must be tested according to EN 12115:2011.

Vacuum resistance to -0.9 bar

Tube: UPE, black, smooth, electrically conductive
Reinforcement: Special rubber foil, textile, 2 crossed copper wires, zinc plated steel wire helix
Cover: EPDM, black, electrically conductive, abrasion resistant, weather resistant, cloth impression
Temperature range: Tube, depending on the discharge medium up to +100°C, hose, flexible down to -35°C. Steam cleaning, without pressure, up to 130°C / max. 30 min

Chemical resistance of rubber hoses table
