DexyFlex®
Hydraulics hose BF 3ТЕ
Hydraulics hose BF 3ТЕ
Application: Petroleum based hydraulic fluids.
Tube: Seamless oil resistant synthetic rubber.
Reinforcement: 2 high resistance synthetic fiber braids.
Cover: Black, oil, weather and abrasion resistant synthetic rubber.
Temperature range: -40°C to +100°C
Safety factor: 4:1
Max. temperature recommended for water base hydraulic fluids: + 70ºC
Max. temperature recommended for air: +50°C
| Article No. | Price (per meter) | Quantity (meters) | Internal Ø mm | Internal Ø inch | External Ø mm | Working pressure (max.) bar | Number of inserts | Bending radius (min.) in mm | Weight approx. kg/m | Coil length (max.) m |
| 0103910300 | 6,96 € |  | 5 | 3/16 | 12.8 | 160 | 3 | 40 | 0.13 | 50 |
| 0103910500 | 7,28 € | | 6 | 1/4 | 14.5 | 145 | 3 | 45 | 0.18 | 50 |
| 0103910700 | 7,26 € | | 8 | 5/16 | 17 | 130 | 3 | 55 | 0.25 | 50 |
| 0103910900 | 8,45 € | | 10 | 3/8 | 18.5 | 110 | 3 | 70 | 0.28 | 50 |
| 0103911100 | 8,83 € | | 12 | 1/2 | 21.8 | 93 | 3 | 85 | 0.44 | 50 |
| 0103911300 | 10,21 € | | 16 | 5/8 | 26 | 80 | 3 | 105 | 0.49 | 50 |
| 0103911500 | 12,34 € | | 19 | 3/4 | 29 | 70 | 3 | 130 | 0.68 | 40 |
| 0103911700 | 15,92 € | | 25 | 1 | 36 | 55 | 3 | 150 | 0.69 | 40 |
