PPV3 - IG

Hydraulic quick coupling



Standart: ISO 7241 - 1 A

Sleeve: double acting

Occlusion: poppet

Locking: radial balls

Material: steel

Finishing: Zn-Fe (Cr III)

Threads: METRIC

Version: BSP, NPT, SAE thread

Standart seals: NBR

Working temperature: -25 C^o - +100 C^o

Optional seals: FKM, EPDM and more

Working pressure: 225-350 bar

Connection under pressure: not allowed
