Pneumatska poliamidna cev PA12 PHL -40°C +110°C. Standardi: DIN 74324 i DIN 73378
Pneumatic Polyamide Hose - PA12 PHL
Manufactured in accordance with DIN 74324 and DIN 73378
Polyamide hose for pressure transmission of Air, Oily air, Technical gases, Oils, Hydraulic oils, Fuels, Lubricants and Greases, Methane (CNG), LPG, Chemicals, Paints, Water, Water based fluids etc.
Technical design features: The PA12 PHL pneumatic polyamide hose is made of specially formulated plasticized polyamide (PA12), stabilized to heat and light, which is extremely resistant to oils, fuels, methane, propane-butane, chemicals and abrasion. This material combines high durability with flexibility and insulating properties.
⭐ ⭐ ⭐ Reduced moisture absorption.
Pressure: PA12 PHL hose is specially designed to operate at high pressures and temperatures.
Temperature Range: It is resistant to temperatures between -40°C and +110°C, maintaining stability and functionality under a variety of conditions.
Operating temperature: -40°C to +100°C.
Operating temperature of water-based fluids +70°C.
Temperature peaks: maximum +110°C.
⭐Compatibility with oils and fuels: PA12 PHL pneumatic polyamide hose is suitable for applications requiring contact with oils, fuels and chemicals.
⭐It does not degrade and does not leak harmful substances, making it suitable for various industrial processes.
⭐Manufactured in accordance with DIN 74324 and DIN 73378.
Protection factor: 1:3.
Colour: Black, Blue and Red.
Black is recommended for outdoor applications.
Applications:
- Air conveying in industrial automation and braking systems.
- Transport of chemicals and hydrocarbons.
- Suitable for outdoor applications.
Manufacturer: ZEC S.p.A. - Italy
| Artikal № | Cena (d.m) | Кoličina (d.m.) | Internal dimension Ø (mm) | External dimension Ø (mm) | Wall thickness (mm) | Working pressure (bar) | Bending radius (mm) | Burst pressure (bar) | Weight g / m | Color |
| 0601010100 | 0,86 € |
| 2 | 4 | 1 | 44 | 16 | 132 | 9,7 | crno |
| 0601010106 | 1,01 € |
| 2 | 4 | 1 | 44 | 16 | 132 | 9,7 | Blue |
| 0601010200 | 1,21 € |
| 3 | 5 | 1 | 33 | 20 | 99 | 12,9 | црн |
| 0601010300 | 1,18 € |
| 4 | 6 | 1 | 28 | 30 | 84 | 16,2 | crno |
| 0601010304 | 1,26 € |
| 4 | 6 | 1 | 28 | 30 | 84 | 16,2 | Red |
| 0601010306 | 1,26 € |
| 4 | 6 | 1 | 28 | 30 | 84 | 16,2 | Blue |
| 0601010400 | 1,80 € |
| 5 | 7 | 1 | 22 | 35 | 66 | 19,4 | crno |
| 0601010500 | 1,60 € |
| 6 | 8 | 1 | 20 | 40 | 60 | 22,6 | crno |
| 0601010504 | 2,06 € |
| 6 | 8 | 1 | 20 | 40 | 60 | 22,6 | Red |
| 0601010506 | 2,06 € |
| 6 | 8 | 1 | 20 | 40 | 60 | 22,6 | Blue |
| 0601010620 | 4,70 € |
| 7 | 10 | 1.5 | 23 | 58 | 69 | 41,2 | crno |
| 0601010700 | 1,99 € |
| 8 | 10 | 1 | 16 | 60 | 48 | 29,1 | crno |
| 0601010704 | 2,84 € |
| 8 | 10 | 1 | 16 | 60 | 48 | 29,1 | Red |
| 0601010706 | 2,84 € |
| 8 | 10 | 1 | 16 | 60 | 48 | 29,1 | Blue |
| 0601010800 | 4,49 € |
| 8 | 11 | 1.5 | 21 | 60 | 63 | 46,1 | crno |
| 0601010900 | 3,58 € |
| 9 | 12 | 1.5 | 20 | 60 | 60 | 50,9 | crno |
| 0601010910 | 3,55 € |
| 10 | 12 | 1 | 12 | 85 | 36 | 35,6 | crno |
| 0601011000 | 4,22 € |
| 12 | 14 | 1 | 10 | 90 | 30 | 42 | crno |
| 0601011100 | 3,96 € |
| 12 | 15 | 1.5 | 16 | 90 | 48 | 65,5 | crno |
| 0601011200 | 6,52 € |
| 12 | 16 | 2 | 20 | 95 | 60 | 90,6 | crno |
| 0601011102 | 9,04 € |
| 15 | 18 | 1.5 | 12 | 140 | 36 | 80,1 | crno |
| 0601011502 | 9,94 € |
| 18 | 22 | 2 | 13 | 200 | 39 | 129,4 | crno |
DIN 74324 and DIN 73378 guarantees:
Material quality: the DIN 74324 and DIN 73378 standards provide clear guidance on the specifications of the polyamide material to be used for the production of the hose. This includes requirements for chemical composition, molecular structure and mechanical properties.
Tests and trials: The standards prescribe various tests and trials to ensure that the hose meets the requirements for pressure, temperature range and chemical resistance. These tests include checks for durability, abrasion resistance and more.
Marking Specifications: Standards require clear and visible marking of the hose with information on its manufacturer, certifications, and maximum working pressure.
The use of PA12 PHL pneumatic polyamide hose, manufactured to DIN 74324 and DIN 73378 standards, ensures high reliability and long product life, which is essential for industrial and automotive applications where durability and safety are paramount. Compliance with these standards is key to ensuring quality and safety in pneumatic systems.
